Bewator Stand Alone Keypad - Single Door, Surface Mounted The compact codelock is straightforward to use with twelve raised buttons that are clearly marked. Housed in a high strength stainless steel housing it is suitable for installation outdoors and for extra weather protection there is a rain hood model SH1 (purchased separately). The code lock controls a single door and uses a voltage free relay contact. Technical Data:. Dimensions: 140 (H) x 80 (W) x 40 (D) mm.

IP Rating: 54. Temperature: -35 to +55° C. Voltage: 12 to 24 V AC/ DC.

Current: 8 mA in standby. Door Capacity: 1. Code capacity: Two four digits. Inputs: Exit button requests with delay. Two separate for codes disable. Outputs: Voltage free relay contact, max 1A, 28 V DC. Opening time: 1-30 sec.

Siemens K42 Manual 1993 dodge manual bewator k42 keypad unsolved problems - fixya eaton clutch replacement manual digicode k42 siemens - user's guide. Siemens/Bewator K42 Manual. Quickcode: 6291 In Stock.

Bewator Stand Alone Keypad - Single Door, Surface Mounted The compact codelock is straightforward to use with twelve raised buttons that are clearly marked. Housed in a high strength stainless steel housing it is suitable for installation outdoors and for extra weather protection there is a rain hood model SH1 (purchased separately). The code lock controls a single door and uses a voltage free relay contact. Technical Data:. Dimensions: 140 (H) x 80 (W) x 40 (D) mm.

IP Rating: 54. Temperature: -35 to +55° C. Voltage: 12 to 24 V AC/ DC.

Current: 8 mA in standby. Door Capacity: 1. Code capacity: Two four digits.

Siemens Manuals Online

Inputs: Exit button requests with delay. Two separate for codes disable. Outputs: Voltage free relay contact, max 1A, 28 V DC. Opening time: 1-30 sec.

. Not Sure What You Need? We're here to help! Whether you're looking to upgrade or replace an existing system, or need a completely new and unique solution taylored to your requirements; we'd love to get involved! You can get in touch with us at our and we'll do everything we can to help!. Don't Miss This! The Bewator K42 is now part of Siemans, the K42 is a compact keypad entry system that can have up to 2 x 4 digit codes and is designed for single door entry use.

The manufacture states that the K42 can be used for internal or external use, this model does have an IP67 rating, although we would recommend this to be used on internal doors only. Separate covers can be available upon request. The case itself is designed to be easily and quickly mounted onto a wall or door frame and is made from solid stainless steel. The keys are backlit which aid code entry during low light hours or situations, they are also vandal resistant with their stainless steel design.

Backlit buttons. Programming done internally (jumper pins). Lock open time 1-30 seconds.

High security keys required for code change. Non-volatile memory. We've suggested some possible options for locking solutions and other accessories here as well, however if you would like to view our full range of electronic locking devices please click the link below: Should you require any additional advice or have any questions please do get in touch - you can give us a call, email or use our Live Chat here on the website. Finish Stainless Steel brand BEWATOR - SIEMENS Depth 40mm Door Open Time 1-30 seconds Programming Done internally (jumper pins) Relay Rating Max 1 amp @ 12/24V AC/DC Case Depth 40mm Case width 80mm Access Length 140 Weather Resistant Yes Current Consumption 0.035A Lock Relay Max 1 amp @ 12/24V AC/DC Supply Voltage 12/24V AC/DC Code Length 4 digits Number Of Codes 2 Access Rating External Audible Indication No Visual Indication Yes Connections Terminals Controller Required No Width 80mm Height 140mm. My name is Darrel and I'm the head of the tech team here at LocksOnline.co.uk.

Thanks for taking some time to tune in and have a look at one of our product review videos. Today we're looking at the code lock, the K42 manufactured by a company called Bewater or Bewater, depending on how you pronounce it. Now actually owned by the company Siemens, which is quite a big electronic company. But needless to say, this particular product has been around for a long, long time. I remember when I was on the tools fitting this particular K42 keypad, so I'm quite familiar with it. And it has some unique designs.

Siemens Technical Manuals

I mean, one of the benefits is it's not quite that much costly, which is a really good plus. And it has some really, really good features. It's easy to program, and it's simple to operate, etc. So let's get down into the nitty gritty of it and let's have a look at it in a little bit more detail. So here you go. Here's the actual code lock again.

It's made out of a cast, as opposed to a plastic, so again it's very, very durable in that respect. And of course, the bottom as you can feel is very, very tactile there. Good, positive action there in regards to the buttons, and probably one of the popularities with this particular type of one is that it's built to last, and you can tell there by the design, etc. The centre button there, number five, has got the raised little blip on it, that allows you then to centralise your fingers should you be hard not to be able to see the actual numbers. So that's great. It has also indicators on here to tell you whether or not the door is going to be open and so forth, and give you information regarding the operation of the actual code lock itself. Now the key here, which you would have normally, it would come with a set of keys, and they've changed the design slightly on these new ones.

Before it used to be just a little cam and you'd turn it and then pull the actual cam out. They've changed that now to a threaded version, so you've got to keep on turning it to get it out, so it's probably a lot more durable and a lot stronger than the old type as well. Just a little bit of a top tip for you as well, even on the older versions you will have here a little serial number and some of the older models of the K series, K42, would have a number stamped on here, and normally it'll be the key number. Like for an example, this one here is key number 12. Can you zoom in the close-up to see that? Okay, so that's key number 12, which means that this is key number 12. So if you lose your key, if you look underneath it, you can find out what they key number is and we can order you up spare keys should you lose your keys.

So that's a little bit of a top tip for you there. Now also as well, what I've noticed on the new ones as well, they've put two little drain holes in the bottom here as well to allow if moisture does get in, then the ideal thing is to let it get out, so that's what that may be designed there. Now I've taken the back off this one. And as you can see here again, solid cast construction.

Brilliant for screwing onto any form of substrate and on the back here as well they've got this sponge pad. And the sponge pad then will seal it in against the bricks or the mortar or whatever you're deciding to fit it to. It also has a tamper button here, so if anybody tries to physically attack it, then it can create tamperer SP alarm that is situated on the inside. So if we go on in a little bit further here now, what you will see inside here, is you've got the power supply there. No problem at all as you can see, and that's where you put your 12 volts, 24 volts, or 12 volt power supply into it.

You've got a set of contacts there at the bottom which the contacts will connect to your strike release or to your mag, etc. And on the other side here then you've got the ability to alter your timers, etc., and also a push to release button should you want to.

It has the ability as well, you can see it on the new one here. You can change the time as well. Sorry, you can change the light. Just have it on or off on the front as well if you want. And also here as well it's got the timer here as to how long the release is released once you've actually pressed in your buttons, so maybe three up to five seconds to release, and then it would relock again. This is the actual part where you would change the codes.

Now you can put two codes in there. It clearly shows there, code one, code two. And you can have two separate codes there operating this particular type of lock.

So it's a good all-around key coded lock. It just works. Sometimes it's so simple in its design, and probably one of its reasons why it's popular is because it just works. There's no programming so to speak where you've got to have a master code and stuff like that. You just take it off, change your code around, pop it back on, screw it back onto the wall, job done. It's as simple as that. So it does have its unique advantages in that respect.

I can't think of anything else more to say about it, but if you're thinking, 'Oh that sounds ideal' for you, or if that's exactly what you want, then great. This might be the product that you're looking for. But if there's something that you do need a bit more information about, feel free to give us a call. We'd love to hear from you and more importantly, we'd love to see you as a customer.

So pop on our site SP, use our email, use our live chat, or by all means, just pop on, give us a call. Either way, we'd love to see you, and I like I said, we'd love to see you as a customer.

So from me, Darrel, and all of us here at LocksOnline, many thanks and catch up with you real soon. Bye, bye now.
